Fireproof (FR) Aluminum Composite Panel

ALUSIGNPANEL Fire-resistant Aluminum composite panel is made of fireproof plastic core with two layers of aluminum sheet. It is one kind of new green material. Because of the additional fireproof element, its fire-resistant feature can reach B1 FR Grade with the FR property test of GB/T8627.

Raw Materials

Aluminum base material: high strength aluminum alloy sheet

Core: non-toxic Fire-resistant (FR) core

Surface: Polyester or PVDF Kynar coating

Specification

Width	1220mm, 1250mm, 1500mm
Length	Upon request, but preferably <5800mm
Panel Thickness	2mm~ 6mm
Alu.Skin Thickness	0.21mm~0.50mm: 0.21mm, 0.30mm, 0.40mm, 0.50mm
Standard Size	1220mm x 2440mm (4' x 8'); 1500mm x 3050mm (5' x 10')
Colors	Factory’s standard 45 colors for reference
Others	Accept custom size and colors too

Advantage

v Easy maintenance

v Easy processing

v Colorful surface

v Hard-burning, FR B1 Grade

v Non-toxicity and safety

v Excellent coating property

Fire-resistance Performance Standard

No.	China	Germany	U.S.A.	France	U.K.
No.	GB/T8627	DIN 4102	ASTM E84	NFF16-101	BS-476
1	A1, A2	A1, A2	NC	MO	O
2	B1	B1	A	M1, M2	1
3	B2	B2	B, C	M3	2, 3

Level and Combustion Property

Degree	Item	Degree	Item
A	None-combustion	B1	Hard-combustion
B2	Combustion	B3	Combustible
Degree	Material	The Combustion Performance Indicators
None-combustion	Class A Material	According to GB/T8625 test, the average length of the remaining≤35cm (including any residual specimen length≥20cm) for each test and average flue gas temperature peak≤150℃, no specimen back burner the scene; According to GB/T8627 test, their smoke density levels (SDR)≤15; According to GB/T14002 and GB/T14403 test, its calorific value≤4.2MJ/kg, and the specimen thermal emission per unit area≤16.8MJ/m2; Toxicity materials combustion flu gas of the entire non-lethal concentration of≥25 mg/L.
Hard-combustion	Class B1 Material	According to GB/T8626 test, its combustion properties should be met GB/T8626, and does not allow any dropping of combustion burn the filter paper; According to GB/T8625 test, the average of each specimen remaining length≥15cm (including any residual specimen length≥0cm), and average peak temperature of gas≤200℃in each test. According to GB/T8627 test, their smoke density levels (SDR)≤75.

Class B1 Burning Test

No.	Test Item	Test Method	Technical Index	Result
1	Minimum value of remaining length after burning (mm)	GB/T8625-88	> 0	480
2	Average value of remaining length after burning (mm)	GB/T8625-88	≥ 150	160
3	Temperature of smoke (℃)	GB/T8625-88	≤ 200	78
4	Height of fire (mm)	GB/T8625-88	≤150	12
5	Grade of smoke density	GB/T8627-88	< 75	9
